TB Series Drum/Barrel Pumps

Drum/Barrel Pumps - TBS Drum Pumps

Lightweight pumps suitable for low to medium viscosity mild corrosives, solvents, and chemicals.


Applications

  • Light acids and bases
  • Solvents

Specifications

Motors

Video

Downloads

Available Lengths 40 in (102 cm)
Tube Diameter 1-1/2 in (3.8 cm)
Discharge Size 1 in (2.54 cm)
Discharge Type Hose Barb
Hose Size 1 in (2.54 cm)
Maximum Temperature 150º F (66º C)
Minimum Temperature -20º F (-29º C)
Electric Motor Air Motor
Maximum Flow 20 gpm (75.7 lpm) 15 gpm (57 lpm)
Maximum Head 28 ft (8.53 m) 16 ft (4.9 m)
Maximum Specific Gravity 1.4 1.4
Maximum Viscosity 200 cP 200 cP
Tube Material 316 stainless steel
Shaft Material 316 stainless steel
Spacer Material FEP
Compressor Material PTFE with stainless steel pin

M3V, M5V, M3V-UK, M5V-US

M3T, M3TV, M5T, M5TV

M3XV, M5XV

M6, M6X

ODP (Open Drip Proof), Splashproof, IP24 Variable Speed Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M3V QPS 115V/50-60Hz 650/400 3,500-10,000 200 cP
M5V CE 230V/50-60Hz 650/400 3,500-10,000 200 cP
M5V-US CE 230V/50-60Hz 650/400 3,500-10,000 200 cP
M3V-UK CE 115V/50-60Hz 650/400 3,500-10,000 200 cP

*Suitable for 230V, 60 Hz. Includes NEMA 6-15 plug

TEFC (Totally Enclosed Fan Cooled) IP55 Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M3T QPS 115V/60Hz 1000/680 12,000 200 cP
M5T CE 230V/50-60Hz 1000/680 12,000 200 cP
M3TV QPS 115V/60Hz 1000/680 0-12,000** 200 cP
M5TV CE 230V/50-60Hz 1000/680 0-12,000** 200 cP

Explosion Proof Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M3XV QPS 115V/60Hz 1000/680 0-12,000** 200 cP
M5XV CE 230V/50-60Hz 1000/680 0-12,000** 200 cP

**Variable speed

Air Motors*

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M6 CE 80-100psi@15-32 cfm 400 300-9,000 1000 cP
M6X CE 80-100psi@15-32 cfm 600 300-6,000 1000 cP

*† An air motor is a non-electrical device meaning possibility of explosion from igniting flammables is reduced.

Specifications


Available Lengths 40 in (102 cm)
Tube Diameter 1-1/2 in (3.8 cm)
Discharge Size 1 in (2.54 cm)
Discharge Type Hose Barb
Hose Size 1 in (2.54 cm)
Maximum Temperature 150º F (66º C)
Minimum Temperature -20º F (-29º C)
Electric Motor Air Motor
Maximum Flow 20 gpm (75.7 lpm) 15 gpm (57 lpm)
Maximum Head 28 ft (8.53 m) 16 ft (4.9 m)
Maximum Specific Gravity 1.4 1.4
Maximum Viscosity 200 cP 200 cP
Tube Material 316 stainless steel
Shaft Material 316 stainless steel
Spacer Material FEP
Compressor Material PTFE with stainless steel pin

Motors


M3V, M5V, M3V-UK, M5V-US

M3T, M3TV, M5T, M5TV

M3XV, M5XV

M6, M6X

ODP (Open Drip Proof), Splashproof, IP24 Variable Speed Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M3V QPS 115V/50-60Hz 650/400 3,500-10,000 200 cP
M5V CE 230V/50-60Hz 650/400 3,500-10,000 200 cP
M5V-US CE 230V/50-60Hz 650/400 3,500-10,000 200 cP
M3V-UK CE 115V/50-60Hz 650/400 3,500-10,000 200 cP

*Suitable for 230V, 60 Hz. Includes NEMA 6-15 plug

TEFC (Totally Enclosed Fan Cooled) IP55 Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M3T QPS 115V/60Hz 1000/680 12,000 200 cP
M5T CE 230V/50-60Hz 1000/680 12,000 200 cP
M3TV QPS 115V/60Hz 1000/680 0-12,000** 200 cP
M5TV CE 230V/50-60Hz 1000/680 0-12,000** 200 cP

Explosion Proof Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M3XV QPS 115V/60Hz 1000/680 0-12,000** 200 cP
M5XV CE 230V/50-60Hz 1000/680 0-12,000** 200 cP

**Variable speed

Air Motors*

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M6 CE 80-100psi@15-32 cfm 400 300-9,000 1000 cP
M6X CE 80-100psi@15-32 cfm 600 300-6,000 1000 cP

*† An air motor is a non-electrical device meaning possibility of explosion from igniting flammables is reduced.
