HVDP Series Drum/Barrel Pumps

Drum/Barrel Pumps - HVDP-HR Drum Pumps

This progressive cavity, positive displacement-style pump can handle viscous fluids up to 100,000 centipoise! The heavy duty HVDP offers multiple mechanical seal choices and materials options for ultimate compatibility. Choose from the HR model (up to 20,000 cP) or the LR model (up to 100,000 cP).

Features include:

  • Unique camlock feature for quick disassembly
  • Optional foot design for drums with liners
  • FDA-compliant options
  • Bellows Type 21 mechanical seal

Applications

  • Waxes
  • Oils
  • Resins
  • Solvents
  • Adhesives
  • Silicone
  • Lotions
  • Honey
  • Juice concentrate
  • Hair & bath gel
  • Corn syrup

Specifications

Motors

Video

Downloads

Available Lengths  27, 40, 48 in (69, 102, 122 cm)
Tube Diameter 2 in (5.1 cm)
Discharge Size 1-1/2 in (3.8 cm) or 2 in (5.1 cm)
Discharge Types Hose barb or tri-clamp
Hose Type 1-1/2 in (3.8 cm) or 2 in (5.1 cm)
Electric Motor Only
Maximum Flow 9 gpm (32 lpm)
Maximum Head 300 ft (91 m)
Maximum Specific Gravity 1.8
Maximum Viscosity 20,000 cP
Tube Material 316 stainless steel
Shaft Material 316 stainless steel
Stator Materials Buna, FKM, or PTFE
Seal Materials Carbon, Ceramic, FKM, EPDM, SiC, Buna, or Kalrez®
O-ring Materials Buna, FKM, EPDM, or PTFE encapsulated silicone
Maximum Temperature 180º F (82º C)
Minimum Temperature -20º F (-29º C)

M73-78

M60-64, M67, M69

M65, M66

TEFC (Totally Enclosed Fan Cooled) IP55 Variable Speed HR Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M73 QPS 115V/60Hz 1000/680 12,000 10,000 cP
M74 CE 230V/50-60Hz 1000/680 12,000 10,000 cP
M75 QPS 115V/60Hz 1000/680 0-12,000 20,000 cP
M76 CE 230V/50-60Hz 1000/680 0-12,000 20,000 cP

Explosion Proof Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M77 QPS 115V/60Hz 1000/680 W 0-12,000 20,000 cP
M78 CE 230V/50-60Hz 1000/680 W 0-12,000 20,000 cP

* Carries independent testing laboratory approval.
** Input power for induction motors will vary by manufacturer.

* An air motor is a non-electrical device meaning possibility of explosion from igniting flammables is reduced.
† Suitable for hazardous areas that do not require independent verification.

Specifications


Available Lengths  27, 40, 48 in (69, 102, 122 cm)
Tube Diameter 2 in (5.1 cm)
Discharge Size 1-1/2 in (3.8 cm) or 2 in (5.1 cm)
Discharge Types Hose barb or tri-clamp
Hose Type 1-1/2 in (3.8 cm) or 2 in (5.1 cm)
Electric Motor Only
Maximum Flow 9 gpm (32 lpm)
Maximum Head 300 ft (91 m)
Maximum Specific Gravity 1.8
Maximum Viscosity 20,000 cP
Tube Material 316 stainless steel
Shaft Material 316 stainless steel
Stator Materials Buna, FKM, or PTFE
Seal Materials Carbon, Ceramic, FKM, EPDM, SiC, Buna, or Kalrez®
O-ring Materials Buna, FKM, EPDM, or PTFE encapsulated silicone
Maximum Temperature 180º F (82º C)
Minimum Temperature -20º F (-29º C)

Motors


M73-78

M60-64, M67, M69

M65, M66

TEFC (Totally Enclosed Fan Cooled) IP55 Variable Speed HR Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M73 QPS 115V/60Hz 1000/680 12,000 10,000 cP
M74 CE 230V/50-60Hz 1000/680 12,000 10,000 cP
M75 QPS 115V/60Hz 1000/680 0-12,000 20,000 cP
M76 CE 230V/50-60Hz 1000/680 0-12,000 20,000 cP

Explosion Proof Motors

Model Certifications Requirements Input/Output
(W)
RPM Maximum Viscosity
M77 QPS 115V/60Hz 1000/680 W 0-12,000 20,000 cP
M78 CE 230V/50-60Hz 1000/680 W 0-12,000 20,000 cP

* Carries independent testing laboratory approval.
** Input power for induction motors will vary by manufacturer.

* An air motor is a non-electrical device meaning possibility of explosion from igniting flammables is reduced.
† Suitable for hazardous areas that do not require independent verification.
