KC/MSKC Series Pumps

KC/MSKC Series Pumps

Sealless Mag-Drive Centrifugal Pumps

  • MSKC is a sealless multi-stage pump for high-pressure/low-flow applications
  • For KC Series pumps, next generation mag drive pumps, the DB Series, are now available. Finish Thompson continues to provide product, parts and support for the KC Series. For technical fliers, curve books, and manuals please see Centrifugal Downloads in the Resources section of the website.

Series Features

  • Sealless mag drive technology - eliminates costly seal problems
  • Multi-Stage design: Generates increased head at low flow rates
  • Low power consumption, wide hydraulic envelope allows for mix and match impeller sizes
  • Small footprint - avoids large impeller diameters
  • Unique interconnecting drive shaft - transmits torque from magnetic coupling to first stage impeller
  • Independent thrust bearings at each stage for maximum reliability
  • Polypropylene or PVDF construction
  • Accepts standard NEMA 56C or IEC 71/B14, 80/B14 frame motors
  • CE/UKCA/EAC certified

SPECIFICATIONS

  • Maximum working pressure 80 psi (5.5 bar)
  • Maximum viscosity: 100 cP
  • Maximum temperature: - Polypropylene: 180°F (82°C) | - PVDF: 220°F (104°C)
  • Maximum flow: 60 gpm (13.6m3/hr.)
  • Maximum head: 100 feet (30.4 meters)

Downloads
